Aruba AP-565 AX1499 Dual Band WiFi 6 Access Point, White (R4W44A)
$1,757.00
Per each
Aruba AP-565 AX1499 Dual Band WiFi 6 Access Point, White (R4W44A)
Item #:
901-IM18AZ909
Model #:
R4W44A
Brand:
Aruba
Not yet rated. Be the first to
Write a review!
$1,757.00
Per each
Want an extra discount today, and every day? Start your free trial.
Aruba AP-565 AX1499 Dual Band WiFi 6 Access Point, White (R4W44A)
Description
Weatherproof and temperature hardened, Aruba 560 series access points deliver cost-effective Wi-Fi 6 wireless connectivity in outdoor and environmentally challenging locations. Purpose-built to survive in the harshest outdoor environments, 560 series can withstand exposure to extreme high and low temperatures, persistent moisture and precipitation, and are fully sealed to keep out airborne contaminants. All electrical interfaces include industrial strength surge protection. Aruba Wi-Fi 6 access points provide high-performance connectivity for any organization experiencing growing numbers of IoT and mobility requirements. With maximum aggregate on air data rate of 1.49Gbps (HE80/HE20), they deliver the speed and reliability needed for most environments. The Aruba advanced ClientMatch technology and an integrated Bluetooth beacon can help enable Aruba location services.
- Weatherproof and temperature-hardened, this access point delivers cost-effective dual-band (2.4GHz, 5GHz) Wi-Fi 6 wireless connectivity in outdoor and environmentally challenging locations
- With maximum aggregate on-air data rate of 1.49Gbps (HE80/HE20), the AP delivers the speed and reliability needed for most environments
- AP can be configured to enable or disable capabilities based on available PoE power, perfect when wired switches have exhausted their power budget
- Wi-Fi 6 access point provide high-performance connectivity for any organization experiencing growing numbers of IoT and mobility requirements
- Features 1 x Ethernet wired network port (RJ45) and 1 x USB Type-C console interface
- Meets or exceeds the FCC/ISED, CE Marked, RED Directive 2014/53/EU, EMC Directive 2014/30/EU, Low Voltage Directive 2014/35/EU, UL/IEC/EN 60950, EN 60601-1-1, EN60601-1-2, TAA standards
- Low-density parity check (LDPC) for high-efficiency error correction and increased throughput
- Advanced Cellular Coexistence (ACC) minimizes interference from cellular networks
- 2.4GHz band maximum (conducted) transmit power (limited by local regulatory requirements): +23dBm per chain, +26dBm aggregate (2 x 2); 5GHz band: +23dBm per chain, +26dBm aggregate (2 x 2)
- Supported modulation types: 802.11b: BPSK, QPSK, CCK; 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM (proprietary extension); 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM (proprietary extension); 802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
- 5GHz: two spatial stream single-user (SU) MIMO for up to 1.2Gbps wireless data rate with individual 2SS HE80 802.11ax client devices or with two 1SS HE80 802.11ax MU-MIMO capable client devices simultaneously; 2.4GHz: two spatial stream single-user (SU) MIMO for up to 574Mbps (287Mbps) wireless data rate with individual 2SSHE40 (HE20) 802.11ax client devices or with two 1SS HE40 (HE20) 802.11ax MU-MIMO capable client devices simultaneously
- Each AP provides connectivity for a maximum of 256 associated clients per radio (512 in total)
- Aruba advanced ClientMatch technology and an integrated Bluetooth beacon can help enable Aruba location services
- Minimum operating system software versions: ArubaOS and Aruba InstantOS 8.8.0.0
- Dimensions: 6.5"H x 6.5"W x 4.3"D
- Regulatory domain: United States of America
- Lifetime manufacturer limited warranty
Specifications
Antenna
Built-in omni-directional antennas: 5GHz antennas 5.4dBi; 2.4GHz antennas 3.2dBi; BLE/802.15.4 antennas 3.3ddBi
Brand
Aruba
Compatible Operating System
ArubaOS and Aruba InstantOS 8.8.0.0
Connector, Port or Interface Type(s)
(1) Ethernet wired network port (RJ-45), (1) USB-C console interface
Data Transfer Rate
Up to 1.49Gbps
Data Transfer Rate (Gbps)
1.49
Data Transfer Rate (Mbps)
1499
Depth in Inches
4.3
Frequencies
2.4GHz and 5GHz
Frequency (Wireless)
Dual Band 2.4/5GHz
Gaming
Non Gaming
Height in Inches
6.5
Max. Data Transfer Rate (Mbps)
1000 - 1499
Power Over Ethernet
Yes
Power Source
PoE
Series or Collection
AP-565
True Color
White
Warranty Information
Limited Lifetime Warranty
Weight (lbs.)
2.27
Width in Inches
6.5
WiFi Standard
WiFi 6
Wireless Bands
Dual Band
Wireless Connectivity
802.11ax
Wireless Standard
AX
