Juniper EX4100 48-Port Gigabit Ethernet PoE+ Managed Switch, Gray (EX4100-48P)
Item #:
901-IM106ZB97
Model #:
EX4100-48P
Brand:
Juniper
Not yet rated. Be the first to
Write a review!
Loading...
Out of stock
$10,211.00
Per each
Upgrade to get 5% off, earn points 10% faster and more. Annual fee of $49.99.
Item is out of stock in your zip code 60069. Please try another zip code or see Other alternate products similar to this item
Description
The Juniper Networks EX4100 line of Ethernet Switches offers a secure, cloud-ready portfolio of access switches ideal for enterprise branch, campus, and data center networks. The EX4100 switches combine the simplicity of the cloud, the power of Mist AI, and a robust hardware foundation with best-in-class security and performance to deliver a differentiated approach to access switching in the cloud, mobile, and IoT era. With Juniper Mist Wired Assurance, the EX4100 line of Switches can be effortlessly onboarded, configured, and managed from the cloud. This simplifies operations, improves visibility, and ensures a much better experience for connected devices.
- Managed switch with 48 x 10/100/1000BASE-T PoE+, 4 x 10GbE uplink, and 4 x 25GbE stacking/uplink ports
- The EX4100-48P, which offers 48 x 1GbE PoE+ access ports, delivering up to 30W per port with an overall total 1440 W of PoE power budget (using two power supplies)
- Features 188 Gbps (unidirectional) and 376 Gbps (bidirectional) packet switching capacities
- Comes in 1 RU form factor
- SNMP: v1, v2c, v3; RFC 1157 SNMPv1, RFC 2011 SNMPv2 for Internet Protocol using SMIv2, RFC 2012 SNMPv2 for transmission control protocol using SMIv2
- Quality of Service (QoS): L2 QoS, L3 QoS, ingress policing: one rate two color, 12 hardware queues per port (eight unicast plus four multicast), Strict priority (SP) and weighted deficit round-robin (WDRR) scheduling methods (egress), 802.1p, (DSCP)/IP precedence trust and marking, L2-L4 classification criteria
- Power consumption: 920W
- Meets or exceeds CAN/CSA-C22.2 No. 62368-1 and 60950-1, UL 62368-1 and 60950-1, IEC 62368-1 and 60950-1 (All country deviations): CB Scheme report, IEC 62368-3 for USB and PoE: CB Scheme report, CFR, Title 21, Chapter 1, Subchapter J, Part 1040, REDR c 1370 OR CAN/CSA-E 60825-1- Part 1, IEC 60825-1, IEC 60825-2, TAA standards
- Switch can be configured to deliver fast PoE capability, which enables the switches to deliver PoE power to connected PoE devices within a few seconds of power being applied to the switch
- Switch offers 4 x 1/10GbE small form-factor pluggable plus transceiver (SFP+) fixed uplink ports, and 4 x 10GbE/25GbE SFP28 ports to support Virtual Chassis connections, which can be reconfigured for use as Ethernet ports for uplink connectivity
- Features 1.7 GHz ARM CPU, 4GB with Error Correcting Code (ECC) DRAM and 8GB storage
- Nonstop bridging and nonstop active routing: NSB and NSR ensure that control plane protocols, states, and tables are synchronized between primary and standby REs to prevent protocol flaps or convergence issues following an RE failover
- To avoid the complexities of STP without sacrificing network resiliency, the switch employs redundant trunk groups to provide the necessary port redundancy and simplify switch configuration
- Cross-member link aggregation allows redundant link aggregation connections between devices in a single Virtual Chassis configuration, providing an additional level of reliability and availability
- IPv4 and IPv6 Layer 3 routing (OSPF and BGP) is available with a Flex license, enabling highly resilient networks
- Switch support IEEE 802.1ae MACsec with AES-256-bit encryption to increase security of point-to-point traffic communications, MACsec provides encrypted communication at the link layer that is capable of identifying and preventing threats from denial of service (DoS) and other intrusion attacks
- Dimensions: 1.72"H x 17.36"W x 13.78"D
- Lifetime manufacturer limited warranty
Specifications
Address Database Size
64000
Auto-Detecting
Yes
Auto-Sensing
Yes
Brand
Juniper
Data Rate Performances
10/100/1000Base-T
Depth in Inches
13.78
Ethernet Number of Ports
31 to 50
Gaming
Non Gaming
Gigabit Ethernet Uplink
Yes
Height in Inches
1.72
Input Voltage
48-60V max
Jumbo Frame
9216 Bytes
LACP
Yes
Layer
3
Max. Data Transfer Rate (Mbps)
More than 3000
Network Management Type
Managed Switch
Number of Ethernet Ports
48
Performance Class
Gigabit Ethernet
Port Mirroring
Traffic mirroring
Power Over Ethernet
Yes
Power Supply
Redundant, hot-swappable power supplies
Quality of Service
Yes
Series or Collection
EX4100
SNMP
v1, v2c, v3
Stackable
Stackable
Switch Form Factor
Rack Mountable
True Color
Gray
VLAN Support
Yes
Warranty Information
Limited Lifetime Warranty
Weight (lbs.)
10.27
Width in Inches
17.36
Wireless Connectivity
No
