StarTech 25m (82ft) LC to LC (UPC) Duplex OM4 Multimode Fiber Optic Patch Cable, 50/125, Aqua (450FBLCLC25)
$63.99
Per each
StarTech 25m (82ft) LC to LC (UPC) Duplex OM4 Multimode Fiber Optic Patch Cable, 50/125, Aqua (450FBLCLC25)
Item #:
901-IM1HL5058
Model #:
450FBLCLC25
Brand:
StarTech
Not yet rated. Be the first to
Write a review!
Product details
View all details
- OM4 Laser-Optimized Multimode Fiber Cable is immune to EMI and supports up to 100 Gbps Ethernet; Full-duplex zip-cord with color-coded TX/RX connectors enable quick visual identification of polarity and conversion to simplex cabling
- LC/LC connectors with UPC polished ends significantly improves return loss over PC polish; Robust molded connector strain reliefs minimizes wear from bending; Protective Aramid fiber for increased tensile strength
- Individually tested for signal integrity; LSZH (low smoke zero halogen) jacket does not emit toxic fumes if combusted; Safe for enclosed/poorly ventilated spaces; Attenuation value under 2.3dB/km meets or exceeds industry standards
Limited quantity available
2 remaining
$63.99
Per each
StarTech 25m (82ft) LC to LC (UPC) Duplex OM4 Multimode Fiber Optic Patch Cable, 50/125, Aqua (450FBLCLC25)
When you’ll get this item:
Free delivery
Tomorrow, Oct 7
(Order within the next 1 hr and 17 min to be eligible to get this item tomorrow)
Description
The LC to LC Multimode Duplex Fiber Optic Patch cable facilitates reliable connectivity across 40 and 100 Gigabit networks.
25m (82ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord
- OM4 Laser-Optimized Multimode Fiber Cable is immune to EMI and supports up to 100 Gbps Ethernet; Full-duplex zip-cord with color-coded TX/RX connectors enable quick visual identification of polarity and conversion to simplex cabling
- LC/LC connectors with UPC polished ends significantly improves return loss over PC polish; Robust molded connector strain reliefs minimizes wear from bending; Protective Aramid fiber for increased tensile strength
- Individually tested for signal integrity; LSZH (low smoke zero halogen) jacket does not emit toxic fumes if combusted; Safe for enclosed/poorly ventilated spaces; Attenuation value under 2.3dB/km meets or exceeds industry standards
- OM4 LC/LC multimode cable supports 1/10/40/100 Gbps networks; Backward compatible with OM3; For high-density network applications such as SANs, data servers, fiber switches, SFP+, QSFP+, and QSFP28 transceivers
- SPECS: 25m (82ft); Color: Aqua (OM4); LC/LC UPC; 50/125µm Core/Cladding; 850nm or 1300nm LED/VCSEL; Modal Bandwidth: 2000MHz•km at 850nm; Cable OD: 2.9mm; Bend Radius: Static 1.2in (3cm), Dynamic 2.4in (6cm); Backed for Life
- This multimode 50/125µm fiber optic patch cord is backward compatible with OM3 and 1/10/40 Gbps networks, ensuring a reliable connection with legacy fiber environments.
- Housed in a LSZH (Low-Smoke, Zero-Halogen) flame-retardant jacket, this OM4 fiber cable emits low smoke and toxic fumes when exposed to high heat or in the event of a fire. It enables safer cable installations in areas with poor ventilation including some
- Each OM4 fiber cable is also individually tested and certified to be within acceptable optical insertion loss limits for guaranteed compatibility and 100% reliability.
- Use in 40/100 Gigabit Ethernet and fiber-channel applications
Specifications
Brand
StarTech
Fiber Cable Type
Plastic Optical Fiber
Fiber Connector Type
LC
Gigabit
Yes
Selling Quantity
1
Selling Quantity (UOM)
Each
True Color
Teal
