StarTech ET90110WDM2 Black Single Mode Fiber Media Converter Kit
Item #:
901-IM1PG5607
Model #:
ET90110WDM2
Brand:
StarTech
Not yet rated. Be the first to
Write a review!
Loading...
$408.99
Per each
Want an extra discount today, and every day? Start your free trial.
StarTech ET90110WDM2 Black Single Mode Fiber Media Converter Kit
Limited quantity available: 2 remaining
Description
The StarTech ET90110WDM2 single mode fiber media converter kit offers a simple solution for connecting 10/100Base-T networks to remote locations using SC-terminated single mode fiber. It offers WDM, enabling bi-directional communication over a single strand of fiber. This fiber media converter supports standalone operation and is installable into a 20 Slot, 2U rackmount chassis. The media converter comes with rugged steel casing for durability in harsh environments.
- Media converter kit is perfect for environments such as government agencies, where security threats (network tapping, etc.) need to prevented
- Dimensions: 1"H x 3.5"W x 6.3"D
- Comes in black color and rugged steel casing for durability in harsh environments
- System requirements: Windows 10/8.1/8/7 (32/64-bit), Server 2012, 2008 R2, Linux 2.4.x/2.6.x/3.x (tested up to 3.5), ESXi 5.1/5.5
- Has one Fiber Optic SC Duplex female, one female RJ-45 connector
- Max transfer distance: 20 km, Wavelength: 1310 nm, Fiber type: Single mode, Media type supported: Optical fiber/twisted pair
- Maximum data transfer rate: 200 Mbps (full-duplex), Full/half duplex support, Auto MDIX, Form factor: Desktop/rack-mountable
- Power: Input voltage: 115 - 230 VAC, Output voltage: 12 VDC, Input current: 0.36 A, Output current: 1 A, Plug type: M, Source: 2 AC adapters
- Supports IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-FX and IEEE 802.3u 100BASE-TX
- Offers connectivity to a user or network segment that is in an isolated area of a large complex or in another building altogether
- Connects traffic control/monitoring systems at extreme distances to the main office
- Widen network connectivity to remote areas of stadiums, auditoriums or other venues
- Converts 10/100Base-T Ethernet to 100Base-FX fiber optic signals over single mode fiber cable
- Wavelength Division Multiplexing (WDM) fiber cuts cabling costs in half or doubles existing network speed using pre-existing cables
- Temperature: 0 to 60 deg C operating, -10 to 70 deg C storage, Humidity: 10 to 90%
- Contains one local media converter unit, one remote media converter unit, two universal power adapters (NA/UK/EU), one instruction manual
- Meets CE, FCC, RoHS certifications and standards
- Weight: 2.7 lbs.
- Comes with 2 years warranty
Specifications
Brand
StarTech
Depth in Inches
6.3
Height in Inches
1
Selling Quantity
1
Selling Quantity (UOM)
Each
True Color
Black
Weight (lbs.)
2.7
Width in Inches
3.5
