Belkin A3L980-05-BLK-S 5' RJ-45 Male/Male Cat6 Snagless Patch Cable; Black

Get free shipping when you order Belkin A3L980-05-BLK-S 5' RJ-45 Male/Male Cat6 Snagless Patch Cable; Black today at Quill.com. Stack coupons to get free gifts & extra discounts!
Item #: 901-IM1L30506IN
  Model #: A3L980-05-BLK-S
Brand: belkin
Belkin A3L980-05-BLK-S 5 RJ-45 Male/Male Cat6 Snagless Patch Cable; Black
$6.69 Each
Delivery Date:

Enter Zip Code
Parcel
Customers Also Viewed
Description
The Belkin ™ 5' black Cat6 snagless patch cable features RJ-45 50-micron gold-plated male connectors on both the ends for clear signal transmission. This male/male cable is great for VoIP, video and file transfers. It helps to maximize your network speed with higher bandwidth. Patch cable featuring staggered pin configuration, has bare stranded copper conductors for high conductivity and PVC jacket for added durability. It is compatible with Belkin ™ Omniview SMB 1x16 KVM-over-IP switch, SMB 1x8 KVM-over-IP switch and SMB CAT5 KVM switch.
  • Cat6 UTP snagless patch cable is suitable for VoIP, video and file transfers
  • Cable length: 5'
  • Connections: one RJ-45 male connector on both ends
  • PVC Jacket for added durability and 4-pair 24 AWG bare stranded copper conductors for excellent signal transmission
  • Meets ISO/IEC 11801, TIA/EIA-568-B.2-1 standards and certifications
  • Contact material: 50 micron gold-plated
  • Compatible with Belkin Omniview SMB 1x16 KVM-over-IP switch, SMB 1x8 KVM-over-IP switch and SMB CAT5 KVM switch
  • Comes in black color
  • Diameter: 5.9 mm + 0.15 mm jacket
  • Voltage rating: 300 V, Dielectric strength: 1.5 kV (AC)
  • Resistance: 93.8 Ohm/km/20 deg C max, Impedance: 100 Ohm + 15 Ohm at 1 - 550 MHz
  • Mutual capacitance: 56 pF/m max
  • Temperature: 75 deg C
  • Propagation delay: 536 ns/100 m max. at 550 MHz, Structural return loss: 8.6 dB min at 550 MHz
  • Staggered pin configuration ensures optimal data transmission
  • CM flame retardant tested
  • Comes with lifetime limited warranty
Specifications
Brand : Belkin Cable Length (ft) : 5 Cable Use : Data Color Family : Black
Customizable : No Device Type : Computer End 1 Connector Type : RJ45 End 2 Connector Type : RJ45
Ethernet : Yes True Color : Black
Weight : 0.20 lbs. per Each
